Type 1 J1772
J1772 Portable EV Charger – Dual Mode Level 1/Level 2 Charging Solution for Electric Vehicles
Key Features
Dual Charging Modes – Level 1 / Level 2
This portable charger supports both Level 1 (120V) and Level 2 (240V) charging, allowing users to charge their EVs at different power levels depending on their location. It delivers a maximum power output of 3.5 KW at 16A for single-phase charging, ensuring a reliable and efficient charging process. For those seeking faster charging, the 7 KW version with 32A support is available, providing rapid power transfer.
Type 1 EV Charging Plug (J1772 Standard)
The Type 1 (J1772) charging plug ensures compatibility with most EVs on the market, particularly for North American users. This standard plug is widely used for electric vehicles, guaranteeing safe and dependable charging.
Durable Cable and Outer Construction
The charging cable is made with a TPU (Thermoplastic Polyurethane) outer cover, known for its flexibility and durability. The wire gauge for the 3.5KW model is 3*2.5mm² + 0.5mm², with a cable diameter of 11mm, and for the 7KW version, it's 3*6mm² + 0.5mm², with a diameter of 13mm. These cables are built to withstand regular use in various environments, maintaining performance even in harsh conditions.
2.8 Inch LCD Screen
Equipped with a 2.8 inch LCD display, the charger provides real-time information, such as charging status, voltage, and current, giving users full control and transparency over the charging process.
Portable and Convenient Design
Packaged in a robust airplane box, this portable charger is easy to transport and store, making it a convenient solution for EV owners who need flexibility. Whether charging at home, at work, or while traveling, the compact design ensures it can be easily carried and set up wherever needed.
Customizable Plug Options
In addition to the standard US plug, the charger can be equipped with an AU plug or customized to meet specific regional needs. This adaptability makes the charger suitable for a wide range of markets, ensuring compatibility in different countries.
Specifications
● Model: J1772 Portable EV Charger
● Power Output: 3.5KW (16A) or 7KW (32A)
● Wire Gauge: 32.5mm² + 0.5mm² (3.5KW) / 36mm² + 0.5mm² (7KW)
● Cable Diameter: 11mm (3.5KW) / 13mm (7KW)
● Outer Cover Material: TPU
● Plug Type: Type 1 J1772
● Display: 2.8 inch LCD screen
● Package: Airplane box
Applications
Our J1772 Portable EV Charger is designed for use in the electric vehicle industry, providing a convenient, portable charging solution for EV owners. Whether for personal use or fleet charging, it supports both Level 1 and Level 2 charging, offering flexibility and reliability in a compact, user-friendly design.
This product is perfect for home charging or on-the-go use, making it a versatile option for those who need a portable charging solution. Custom plug options and specifications are available to meet the diverse needs of customers in different regions, making it suitable for global distribution.
Why Choose Our J1772 Portable EV Charger?
With our strong background in both manufacturing and trade, we offer high-quality, customizable products that meet international standards. Our J1772 Portable EV Charger is a reliable and efficient solution for the ever-growing electric vehicle market, providing the flexibility, safety, and performance that EV owners need.
